API REFERENCE · v1

ChaosPay API Documentation

Accept QRIS payments, track their status, check your balance and send payouts to your registered bank accounts with a JSON REST API. Every endpoint answers in the same envelope and every notification we send you is signed.

PaymentsCreate a QRIS payment and receive a callback when it is paid. PayoutsWithdraw your balance to a registered bank account by API. WebhooksSigned notifications for every final payment and payout.

Base URL

All API requests are made over HTTPS to:

Production

https://api.labubu4d.lol

Requests use Content-Type: application/json for POST bodies and query parameters for GET. Amounts are whole Indonesian Rupiah (IDR) integers. Times are in Asia/Jakarta (UTC+7).

Quick Start

Get your credentials. Sign in to the merchant dashboard and open 2FA & API. You will find your Merchant Identifier and API Key. The Secret Key is shown only once, when it is issued or rotated, so store it safely then.
Set your callback URL. In Callback Settings, enter the HTTPS URL that should receive payment notifications (and, if you use payouts, the withdrawal callback URL).
Whitelist your server IPs (recommended) in the same place.
Create a payment with POST /payment, show the returned QR code to your customer and wait for the callback.
Test end to end in the sandbox before going live.

cURL

# client_signature = md5(username + amount + secret_key)
curl -X POST https://api.labubu4d.lol/payment \
  -H "Content-Type: application/json" \
  -H "X-API-KEY: YOUR_API_KEY" \
  -d '{
    "merchant": "YOUR_MERCHANT_ID",
    "username": "customer001",
    "amount": 50000,
    "order_id": "INV-10023",
    "client_signature": "3f2a9c0e7b1d4a8e9f6c5b2a1d0e9f8c"
  }'

Sandbox

Each merchant can also issue a sandbox API key and secret from 2FA & API. Use them against the same base URL:

Payments created with the sandbox key are never sent to a bank or provider, never touch your real balance, and come back with "sandbox": true.
On the Sandbox page you can mark a sandbox payment as paid or failed. That sends a real callback to your payment callback URL, signed with your sandbox secret, so you can test your handler.
The IP whitelist is not enforced for sandbox keys.
Payouts and bank account listing are not available in the sandbox (NOT_AVAILABLE_IN_SANDBOX). Balance returns zeros.

Rate Limiting

Limits are applied per API key, per minute. Over the limit, the API answers HTTP 429 with a Retry-After header (seconds).

Endpoint	Limit
`POST /payment`	120 requests / minute
`GET /payment/status`, `GET /account/balance`	300 requests / minute
`POST /payout`, `GET /payout/status`, `GET /account/banks`	30 requests / minute (combined)

These are the defaults. Every limit on this page (payment and payout amounts, daily limits, rate limits, callback attempts and timeout) can be set per account; yours are listed in the dashboard under My Account.

Prefer callbacks over polling. If you do poll a payment status, an interval of a few seconds is plenty.

Authentication

Every request identifies your account with the API key in a header and your merchant identifier in the request (JSON body for POST, query string for GET).

Header	Required	Description
`X-API-KEY`	Required	Your API key (or sandbox API key). Never send it in the URL.
`Content-Type`	POST	`application/json`
`X-Timestamp`	v2	Unix time in seconds. Must be within 5 minutes of our clock.
`X-Nonce`	v2	A random string, 8–64 characters of `A-Z a-z 0-9 _ -`, never reused.
`X-Signature`	v2	Lower-case hex HMAC-SHA256, see Request Signature v2.

Your secret key is used to sign requests and to verify our callbacks. It is never sent in a request. If you think it has leaked, rotate your keys from 2FA & API: a new API key and secret key are issued together and the old pair stops working immediately.

Client Signature (Create Payment)

POST /payment requests that are not signed with v2 must include client_signature:

Formula

client_signature = md5(username + amount + secret_key)

The three values are concatenated as text with no separator, and the result is 32 lower-case hex characters. For username = "customer001", amount = 50000 and secret "sec", the input is customer00150000sec.

Request Signature v2

Signature v2 signs the whole request and protects it against replay. It is required for every payout endpoint (/payout, /payout/status, /account/banks) and accepted on every other endpoint. When a request carries a valid v2 signature, client_signature is not needed. Your account can also be set to require v2 everywhere.

String to sign

METHOD + "\n" + PATH + "\n" + X-Timestamp + "\n" + X-Nonce + "\n" + sha256_hex(PAYLOAD)

X-Signature = hmac_sha256_hex(string_to_sign, secret_key)

Part	Value
`METHOD`	Upper case, e.g. `POST`
`PATH`	The path only, without host or query, e.g. `/payout`
`PAYLOAD`	`POST`: the raw request body, byte for byte. `GET`: the raw query string without the leading `?` (empty string if none).

<?php
// ChaosPay request signature v2
function chaospaySign(string $method, string $path, string $payload, string $secretKey): array
{
    $timestamp = (string) time();
    $nonce = bin2hex(random_bytes(8));
    $stringToSign = implode("\n", [strtoupper($method), $path, $timestamp, $nonce, hash('sha256', $payload)]);

    return [
        'X-Timestamp' => $timestamp,
        'X-Nonce' => $nonce,
        'X-Signature' => hash_hmac('sha256', $stringToSign, $secretKey),
    ];
}

// ChaosPay request signature v2 (Node.js 18+)
const crypto = require('crypto');

function chaospaySign(method, path, payload, secretKey) {
  const timestamp = Math.floor(Date.now() / 1000).toString();
  const nonce = crypto.randomBytes(8).toString('hex');
  const bodyHash = crypto.createHash('sha256').update(payload, 'utf8').digest('hex');
  const stringToSign = [method.toUpperCase(), path, timestamp, nonce, bodyHash].join('\n');

  return {
    'X-Timestamp': timestamp,
    'X-Nonce': nonce,
    'X-Signature': crypto.createHmac('sha256', secretKey).update(stringToSign, 'utf8').digest('hex'),
  };
}

# ChaosPay request signature v2
import hashlib, hmac, secrets, time

def chaospay_sign(method: str, path: str, payload: str, secret_key: str) -> dict:
    timestamp = str(int(time.time()))
    nonce = secrets.token_hex(8)
    body_hash = hashlib.sha256(payload.encode("utf-8")).hexdigest()
    string_to_sign = "\n".join([method.upper(), path, timestamp, nonce, body_hash])
    return {
        "X-Timestamp": timestamp,
        "X-Nonce": nonce,
        "X-Signature": hmac.new(secret_key.encode(), string_to_sign.encode(), hashlib.sha256).hexdigest(),
    }

Common mistakes

Signing one JSON string and sending another (for example, letting your HTTP client re-serialise the body). Send exactly the string you hashed.
Building the query string twice. Build it once, sign it, and append that same string to the URL.
Reusing a nonce: each nonce is accepted once (NONCE_REUSED). A clock more than 5 minutes off gives REQUEST_EXPIRED.

IP Whitelist

In Callback Settings you can list the server IPs allowed to call the API with your live key, separated by |. When the list is empty, any IP is accepted. A request from another IP is refused with IP_NOT_WHITELISTED. We strongly recommend setting it before enabling payouts.

Response Format

Every response, success or failure, is a JSON envelope:

Field	Type	Description
`code`	integer	`200` on success, otherwise the error status
`message`	string	`OK`, or a machine-readable error code
`data`	object \| array \| null	The result; usually `null` on error

Success

{
  "code": 200,
  "message": "OK",
  "data": { }
}

Error

{
  "code": 403,
  "message": "IP_NOT_WHITELISTED",
  "data": null
}

Branch on code and message, not on the HTTP status line alone. When an upstream provider fails, the envelope says 502 while the HTTP status is 503.

Error Codes

HTTP	message	Meaning
400	`INVALID_PARAMETER`	A parameter is missing or has the wrong format.
401	`INVALID_SIGNATURE`	The v2 signature or its headers are malformed or do not match.
401	`REQUEST_EXPIRED`	`X-Timestamp` is more than 5 minutes from our clock.
401	`NONCE_REUSED`	This `X-Nonce` was already used.
401	`SIGNATURE_V2_REQUIRED`	This endpoint (or your account) requires a v2 signature.
403	`API_KEY_REQUIRED`	The `X-API-KEY` header is missing.
403	`INVALID_API_KEY_OR_MERCHANT`	The key and merchant identifier do not match an active account.
403	`IP_NOT_WHITELISTED`	The calling IP is not in your whitelist.
403	`INVALID_CLIENT_SIGNATURE`	`client_signature` does not match.
403	`UNAUTHORIZED`	The request could not be tied to your account.
403	`API_PAYOUTS_DISABLED`	Payouts by API are not enabled for your account. Contact us to enable them.
403	`NOT_AVAILABLE_IN_SANDBOX`	The endpoint does not work with sandbox keys.
404	`TRANSACTION_NOT_FOUND`	No payment with that `transaction_id` / `order_id` on your account.
404	`PAYOUT_NOT_FOUND`	No payout with that `payout_id` / `withdraw_id` on your account.
404	`NOT_FOUND`	Unknown endpoint.
405	`METHOD_NOT_ALLOWED`	Wrong HTTP method for this endpoint.
409	`DUPLICATE_PAYOUT_ID`	The `payout_id` was already used with a different bank account or amount.
422	`INVALID_BANK`	`bank_id` is not one of your registered bank accounts.
422	`AMOUNT_BELOW_MINIMUM`	The payout is below the minimum; `data.minimum` gives it.
422	`AMOUNT_ABOVE_MAXIMUM`	The payout is above your maximum per payout; `data.maximum` gives it.
422	`DAILY_LIMIT_EXCEEDED`	The daily payment volume, payout volume or payout count set for your account is reached. Create Payment returns `data.limit` and `data.used`.
422	`INSUFFICIENT_BALANCE`	Your available balance does not cover the payout amount plus its fee.
429	`TOO_MANY_REQUESTS`	Rate limit exceeded. Wait for `Retry-After` seconds.
500	`SERVICE_ERROR`	Unexpected error on our side. Check the payment status by `order_id` before retrying a payment; a payout is safe to retry with the same `payout_id`.
503 (code 502)	`GATEWAY_UNREACHABLE`, `INVALID_PROVIDER_RESPONSE`, `INVALID_SIGNATURE`	The payment provider could not be reached, or its answer was malformed or failed our signature check. A retry opens a new payment.
503	`PROVIDER_NOT_CONFIGURED`	No payment channel is available for your account right now.

When the payment provider rejects a request, its own code and message are passed through in the envelope, for example {"code": 400, "message": "Amount range is from IDR 10,000 to 10,000,000", "data": null}.

Create Payment

POST/payment

Creates a QRIS payment and returns the QR payload to show your customer. Payments expire at expire_date; the final result is delivered to your payment callback.

Request Body

Parameter	Type	Required	Description
`merchant`	string	Required	Your merchant identifier
`username`	string	Required	Your customer's username or ID (max 191)
`amount`	integer	Required	Amount in IDR. Default range 10,000 – 10,000,000; your account may have its own.
`client_signature`	string	Required*	`md5(username + amount + secret_key)`. *Not needed when the request is signed with v2.
`order_id`	string	Optional	Your own reference, max 64, `A-Z a-z 0-9 . _ : -`. Returned in the response and the callback, and usable to look the payment up.
`email`	string	Optional	Payer email
`mobile`	string	Optional	Payer phone, 6–20 digits, optional leading `+`
`account_name`	string	Optional	Payer name (max 100)
`account_no`	string	Optional	Payer account number, 3–32 digits
`bank_code`	string	Optional	Payer bank code, 2–32 characters

Every request opens a new payment, even with an order_id you already used. After a timeout, look the payment up by order_id before sending the request again, or the customer gets a second QR. A status lookup by an order_id used more than once returns the newest payment.

Example Request

# client_signature = md5(username + amount + secret_key)
curl -X POST https://api.labubu4d.lol/payment \
  -H "Content-Type: application/json" \
  -H "X-API-KEY: YOUR_API_KEY" \
  -d '{
    "merchant": "YOUR_MERCHANT_ID",
    "username": "customer001",
    "amount": 50000,
    "order_id": "INV-10023",
    "client_signature": "3f2a9c0e7b1d4a8e9f6c5b2a1d0e9f8c"
  }'

<?php
$apiKey    = 'YOUR_API_KEY';
$secretKey = 'YOUR_SECRET_KEY';

$body = [
    'merchant' => 'YOUR_MERCHANT_ID',
    'username' => 'customer001',
    'amount'   => 50000,
    'order_id' => 'INV-10023',
];
$body['client_signature'] = md5($body['username'] . $body['amount'] . $secretKey);

$ch = curl_init('https://api.labubu4d.lol/payment');
curl_setopt_array($ch, [
    CURLOPT_POST           => true,
    CURLOPT_POSTFIELDS     => json_encode($body),
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_HTTPHEADER     => ['Content-Type: application/json', 'X-API-KEY: ' . $apiKey],
]);
$response = json_decode(curl_exec($ch), true);

if ($response['code'] === 200) {
    // Show $response['data']['qr'] as a QR code, or redirect to $response['data']['payment_url']
}

// Node.js 18+
const crypto = require('crypto');

(async () => {
  const apiKey = 'YOUR_API_KEY';
  const secretKey = 'YOUR_SECRET_KEY';

  const body = { merchant: 'YOUR_MERCHANT_ID', username: 'customer001', amount: 50000, order_id: 'INV-10023' };
  body.client_signature = crypto.createHash('md5').update(body.username + body.amount + secretKey).digest('hex');

  const res = await fetch('https://api.labubu4d.lol/payment', {
    method: 'POST',
    headers: { 'Content-Type': 'application/json', 'X-API-KEY': apiKey },
    body: JSON.stringify(body),
  });
  const { code, message, data } = await res.json();
  // code === 200 → show data.qr as a QR code, or redirect to data.payment_url
})();

import hashlib, requests

api_key, secret_key = "YOUR_API_KEY", "YOUR_SECRET_KEY"

body = {"merchant": "YOUR_MERCHANT_ID", "username": "customer001", "amount": 50000, "order_id": "INV-10023"}
body["client_signature"] = hashlib.md5(f'{body["username"]}{body["amount"]}{secret_key}'.encode()).hexdigest()

r = requests.post("https://api.labubu4d.lol/payment", json=body, headers={"X-API-KEY": api_key}, timeout=30)
resp = r.json()
# resp["code"] == 200 → show resp["data"]["qr"] as a QR code, or redirect to resp["data"]["payment_url"]

Response

200 OK

{
  "code": 200,
  "message": "OK",
  "data": {
    "transaction_id": "TRX2610211430151234",
    "order_id": "INV-10023",
    "amount": 50000,
    "create_date": "2026-10-21 14:30:15",
    "expire_date": "2026-10-21 14:40:15",
    "status": 0,
    "qr": "00020101021226...6304ABCD",
    "payment_url": null,
    "sandbox": false
  }
}

Field	Type	Description
`transaction_id`	string	Our payment reference. Keep it with your order.
`order_id`	string \| null	Your reference, as sent
`amount`	integer	Amount in IDR
`create_date`	string	`Y-m-d H:i:s`, Asia/Jakarta
`expire_date`	string	After this time the QR can no longer be paid
`status`	integer	`0` on creation, see status codes
`qr`	string	QRIS payload. Render it as a QR code for the customer to scan.
`payment_url`	string \| null	A hosted payment page, when the channel provides one (https only)
`sandbox`	boolean	`true` when created with a sandbox key

Payment Status

GET/payment/status

Returns the current state of one of your payments. Use it to reconcile, or if a callback did not reach you.

Query Parameters

Parameter	Type	Required	Description
`merchant`	string	Required	Your merchant identifier
`transaction_id`	string	One of	Our reference from Create Payment
`order_id`	string	One of	Your reference

Example Request

curl -G https://api.labubu4d.lol/payment/status \
  -H "X-API-KEY: YOUR_API_KEY" \
  --data-urlencode "merchant=YOUR_MERCHANT_ID" \
  --data-urlencode "order_id=INV-10023"

<?php
$query = http_build_query(['merchant' => 'YOUR_MERCHANT_ID', 'order_id' => 'INV-10023']);

$ch = curl_init('https://api.labubu4d.lol/payment/status?' . $query);
curl_setopt_array($ch, [
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_HTTPHEADER     => ['X-API-KEY: YOUR_API_KEY'],
]);
$response = json_decode(curl_exec($ch), true);

if ($response['code'] === 200 && $response['data']['status'] === 1) {
    // paid
}

// Node.js 18+
(async () => {
  const query = new URLSearchParams({ merchant: 'YOUR_MERCHANT_ID', order_id: 'INV-10023' });
  const res = await fetch(`https://api.labubu4d.lol/payment/status?${query}`, { headers: { 'X-API-KEY': 'YOUR_API_KEY' } });
  const { code, data } = await res.json();
  // code === 200 && data.status === 1 → paid
})();

import requests

r = requests.get("https://api.labubu4d.lol/payment/status",
                 params={"merchant": "YOUR_MERCHANT_ID", "order_id": "INV-10023"},
                 headers={"X-API-KEY": "YOUR_API_KEY"}, timeout=30)
resp = r.json()
# resp["code"] == 200 and resp["data"]["status"] == 1 → paid

Response

200 OK

{
  "code": 200,
  "message": "OK",
  "data": {
    "merchant": "YOUR_MERCHANT_ID",
    "transaction_id": "TRX2610211430151234",
    "order_id": "INV-10023",
    "idrpayment_id": "88231907",
    "username": "customer001",
    "amount": 50000,
    "status": 1,
    "local_status": "completed",
    "remark": "",
    "sandbox": false
  }
}

Field	Type	Description
`merchant`	string	Your merchant identifier
`transaction_id`	string	Our reference
`order_id`	string \| null	Your reference
`idrpayment_id`	string \| null	The payment provider's reference
`username`	string	The customer username sent on creation
`amount`	integer	Amount in IDR
`status`	integer	`0`, `1` or `2`, see below
`local_status`	string	`pending`, `completed`, `failed` or `expired`
`remark`	string	Provider remark, if any
`sandbox`	boolean	`true` for sandbox payments

Payment Status Codes

status	local_status	Meaning	Final
`0`	`pending`	Waiting for the customer to pay	No
`0`	`expired`	Not paid before `expire_date`	Yes
`1`	`completed`	Paid. Credit your customer.	Yes
`2`	`failed`	Failed or cancelled	Yes

Only status = 1 means the money was received. Use local_status to tell a pending payment from an expired one.

Balance

GET/account/balance

Returns your current balance. Query parameter: merchant (required).

cURL

curl -G https://api.labubu4d.lol/account/balance \
  -H "X-API-KEY: YOUR_API_KEY" \
  --data-urlencode "merchant=YOUR_MERCHANT_ID"

200 OK

{
  "code": 200,
  "message": "OK",
  "data": {
    "merchant": "YOUR_MERCHANT_ID",
    "currency": "IDR",
    "available": "12500000.00",
    "pending_settlement": "1500000.00",
    "settled_total": "84000000.00"
  }
}

Field	Type	Description
`currency`	string	Always `IDR`
`available`	string	Balance you can withdraw now (decimal string, 2 places)
`pending_settlement`	string	Held for payouts that are not final yet
`settled_total`	string	Total paid out to you so far

Bank Accounts

GET/account/banksSignature v2

Lists the bank accounts registered in your dashboard (Settlement Banks). Use the bank_id when creating a payout. Accounts can only be added from the dashboard. Query parameter: merchant (required). Sign it like any v2 GET, with PATH = /account/banks and PAYLOAD = merchant=YOUR_MERCHANT_ID.

200 OK

{
  "code": 200,
  "message": "OK",
  "data": [
    {
      "bank_id": 12,
      "bank_name": "BCA",
      "account_name": "PT CONTOH MERCHANT",
      "account_number": "123****890",
      "is_default": true
    }
  ]
}

Create Payout

POST/payoutSignature v2

Withdraws from your available balance to one of your registered bank accounts. The amount plus any withdraw fee set for your account is held immediately; the bank receives the full amount. The result is sent to your withdrawal callback URL. Payouts by API have to be enabled for your account by our team first.

Request Body

Parameter	Type	Required	Description
`merchant`	string	Required	Your merchant identifier
`payout_id`	string	Required	Your unique reference, max 64, `A-Z a-z 0-9 . _ : -`
`bank_id`	integer	Required	From Bank Accounts
`amount`	integer	Required	Amount in IDR. Default minimum 10,000; your account may also have a maximum and daily limits.
`note`	string	Optional	Free text, max 191

Idempotency. Repeating a payout_id with the same bank account and amount returns the existing payout; nothing is withdrawn twice. With different values it returns DUPLICATE_PAYOUT_ID.

Example Request

# POST requests signed with v2: the payload is the raw JSON body, byte for byte.
API_KEY='YOUR_API_KEY'; SECRET='YOUR_SECRET_KEY'
BODY='{"merchant":"YOUR_MERCHANT_ID","payout_id":"PO-2026-0001","bank_id":12,"amount":1500000,"note":"October settlement"}'

TS=$(date +%s); NONCE=$(openssl rand -hex 8)
BODY_HASH=$(printf '%s' "$BODY" | openssl dgst -sha256 -hex | sed 's/^.* //')
SIGNATURE=$(printf 'POST\n/payout\n%s\n%s\n%s' "$TS" "$NONCE" "$BODY_HASH" \
  | openssl dgst -sha256 -hmac "$SECRET" -hex | sed 's/^.* //')

curl -X POST https://api.labubu4d.lol/payout \
  -H "Content-Type: application/json" \
  -H "X-API-KEY: $API_KEY" -H "X-Timestamp: $TS" -H "X-Nonce: $NONCE" -H "X-Signature: $SIGNATURE" \
  --data-raw "$BODY"

<?php
// Uses chaospaySign() from the Authentication section.
$payload = json_encode([
    'merchant'  => 'YOUR_MERCHANT_ID',
    'payout_id' => 'PO-2026-0001',
    'bank_id'   => 12,
    'amount'    => 1500000,
    'note'      => 'October settlement',
]);

$headers = chaospaySign('POST', '/payout', $payload, 'YOUR_SECRET_KEY');

$ch = curl_init('https://api.labubu4d.lol/payout');
curl_setopt_array($ch, [
    CURLOPT_POST           => true,
    CURLOPT_POSTFIELDS     => $payload,      // send exactly the bytes you signed
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_HTTPHEADER     => [
        'Content-Type: application/json',
        'X-API-KEY: YOUR_API_KEY',
        'X-Timestamp: ' . $headers['X-Timestamp'],
        'X-Nonce: ' . $headers['X-Nonce'],
        'X-Signature: ' . $headers['X-Signature'],
    ],
]);
$response = json_decode(curl_exec($ch), true);

// Uses chaospaySign() from the Authentication section.

(async () => {
  const payload = JSON.stringify({
    merchant: 'YOUR_MERCHANT_ID', payout_id: 'PO-2026-0001', bank_id: 12, amount: 1500000, note: 'October settlement',
  });

  const res = await fetch('https://api.labubu4d.lol/payout', {
    method: 'POST',
    headers: { 'Content-Type': 'application/json', 'X-API-KEY': 'YOUR_API_KEY', ...chaospaySign('POST', '/payout', payload, 'YOUR_SECRET_KEY') },
    body: payload, // send exactly the string you signed
  });
  const result = await res.json();
})();

# Uses chaospay_sign() from the Authentication section.
import json, requests

payload = json.dumps({"merchant": "YOUR_MERCHANT_ID", "payout_id": "PO-2026-0001", "bank_id": 12,
                      "amount": 1500000, "note": "October settlement"})

headers = {"Content-Type": "application/json", "X-API-KEY": "YOUR_API_KEY",
           **chaospay_sign("POST", "/payout", payload, "YOUR_SECRET_KEY")}
r = requests.post("https://api.labubu4d.lol/payout", data=payload, headers=headers, timeout=30)  # send the exact string you signed
result = r.json()

Response

200 OK

{
  "code": 200,
  "message": "OK",
  "data": {
    "payout_id": "PO-2026-0001",
    "withdraw_id": 41,
    "amount": 1500000,
    "fee": 5000,
    "total_debit": 1505000,
    "status": "pending",
    "bank": {
      "bank_id": 12,
      "bank_name": "BCA",
      "account_number": "123****890"
    },
    "note": "October settlement",
    "requested_at": "2026-10-21T14:32:00+07:00",
    "processed_at": null
  }
}

422

{
  "code": 422,
  "message": "AMOUNT_BELOW_MINIMUM",
  "data": { "minimum": 10000 }
}

Field	Type	Description
`payout_id`	string	Your reference
`withdraw_id`	integer	Our reference
`amount`	integer	Amount in IDR the bank receives
`fee`	integer	Withdraw fee, charged on top of `amount` (0 if none)
`total_debit`	integer	`amount + fee`, taken from your balance
`status`	string	See payout status values
`bank`	object	`bank_id`, `bank_name`, masked `account_number`
`note`	string \| null	Your note
`requested_at`	string	ISO 8601
`processed_at`	string \| null	ISO 8601, set when final

Payout Status

GET/payout/statusSignature v2

Query parameters: merchant (required) and one of payout_id or withdraw_id. The response data has the same shape as Create Payout.

# GET requests signed with v2: the payload is the raw query string, exactly as sent.
API_KEY='YOUR_API_KEY'; SECRET='YOUR_SECRET_KEY'
URI_PATH='/payout/status'
QUERY='merchant=YOUR_MERCHANT_ID&payout_id=PO-2026-0001'

TS=$(date +%s); NONCE=$(openssl rand -hex 8)
BODY_HASH=$(printf '%s' "$QUERY" | openssl dgst -sha256 -hex | sed 's/^.* //')
SIGNATURE=$(printf 'GET\n%s\n%s\n%s\n%s' "$URI_PATH" "$TS" "$NONCE" "$BODY_HASH" \
  | openssl dgst -sha256 -hmac "$SECRET" -hex | sed 's/^.* //')

curl "https://api.labubu4d.lol$URI_PATH?$QUERY" \
  -H "X-API-KEY: $API_KEY" -H "X-Timestamp: $TS" -H "X-Nonce: $NONCE" -H "X-Signature: $SIGNATURE"

<?php
// Uses chaospaySign() from the Authentication section.
$query = http_build_query(['merchant' => 'YOUR_MERCHANT_ID', 'payout_id' => 'PO-2026-0001']);
$headers = chaospaySign('GET', '/payout/status', $query, 'YOUR_SECRET_KEY');

$ch = curl_init('https://api.labubu4d.lol/payout/status?' . $query); // the same query string that was signed
curl_setopt_array($ch, [
    CURLOPT_RETURNTRANSFER => true,
    CURLOPT_HTTPHEADER     => [
        'X-API-KEY: YOUR_API_KEY',
        'X-Timestamp: ' . $headers['X-Timestamp'],
        'X-Nonce: ' . $headers['X-Nonce'],
        'X-Signature: ' . $headers['X-Signature'],
    ],
]);
$response = json_decode(curl_exec($ch), true);

// Uses chaospaySign() from the Authentication section.
(async () => {
  const query = new URLSearchParams({ merchant: 'YOUR_MERCHANT_ID', payout_id: 'PO-2026-0001' }).toString();

  const res = await fetch(`https://api.labubu4d.lol/payout/status?${query}`, { // the same query string that was signed
    headers: { 'X-API-KEY': 'YOUR_API_KEY', ...chaospaySign('GET', '/payout/status', query, 'YOUR_SECRET_KEY') },
  });
  const result = await res.json();
})();

# Uses chaospay_sign() from the Authentication section.
import requests
from urllib.parse import urlencode

query = urlencode({"merchant": "YOUR_MERCHANT_ID", "payout_id": "PO-2026-0001"})
headers = {"X-API-KEY": "YOUR_API_KEY", **chaospay_sign("GET", "/payout/status", query, "YOUR_SECRET_KEY")}

# Put the signed string in the URL yourself; passing params= lets requests re-encode it.
r = requests.get(f"https://api.labubu4d.lol/payout/status?{query}", headers=headers, timeout=30)
result = r.json()

Payout Status Values

status	Meaning	Final
`pending`	Received; the amount is held from your balance	No
`processing`	Being transferred to the bank	No
`success`	Transferred	Yes
`failed`	Rejected or failed; the held amount and fee are returned to your available balance	Yes

Payment Callback

When a payment reaches a final state, we send a POST with a JSON body to your payment callback URL.

Header	Value
`Content-Type`	`application/json`
`Accept`	`application/json`

Payload

{
  "idrpayment_id": "88231907",
  "transaction_id": "TRX2610211430151234",
  "order_id": "INV-10023",
  "amount": 50000,
  "status": 1,
  "signature_v2": "5d1c7e0f6a2b...e93a",
  "sandbox": false,
  "signature": "a8f5f167f44f4964e6c998dee827110c"
}

Field	Type	Description
`idrpayment_id`	string	The payment provider's reference
`transaction_id`	string	Our reference
`order_id`	string \| null	Your reference
`amount`	integer	Amount in IDR
`status`	integer	`1` paid, `2` failed, `0` expired (reported by the provider)
`signature_v2`	string	HMAC-SHA256, verify this one
`signature`	string	Legacy: `md5(transaction_id + amount + secret_key)`. Kept for older integrations; it does not cover `status`.
`sandbox`	boolean	`true` for sandbox payments

Verifying the signature

Formula

signature_v2 = hmac_sha256_hex(transaction_id|order_id|amount|status|idrpayment_id, secret_key)

Join the five values with |, using an empty string when order_id is null. Compare in constant time.

<?php
$secretKey = 'YOUR_SECRET_KEY';
$p = json_decode(file_get_contents('php://input'), true);

$expected = hash_hmac('sha256', implode('|', [
    $p['transaction_id'], $p['order_id'] ?? '', $p['amount'], $p['status'], $p['idrpayment_id'],
]), $secretKey);

if (! hash_equals($expected, (string) ($p['signature_v2'] ?? ''))) {
    http_response_code(401);
    exit('invalid signature');
}

// Idempotent: the same notification may arrive more than once.
if ((int) $p['status'] === 1) {
    // mark order $p['order_id'] / $p['transaction_id'] as paid (once)
}

http_response_code(200);
echo 'OK';

// Express example
const crypto = require('crypto');

app.post('/chaospay/callback', express.json(), (req, res) => {
  const p = req.body;
  const expected = crypto.createHmac('sha256', 'YOUR_SECRET_KEY')
    .update([p.transaction_id, p.order_id ?? '', p.amount, p.status, p.idrpayment_id].join('|'))
    .digest('hex');

  const given = Buffer.from(String(p.signature_v2 || ''));
  if (given.length !== expected.length || !crypto.timingSafeEqual(given, Buffer.from(expected))) {
    return res.status(401).send('invalid signature');
  }

  if (Number(p.status) === 1) {
    // mark the order as paid (once — notifications can repeat)
  }
  res.status(200).send('OK');
});

# Flask example
import hashlib, hmac
from flask import Flask, request

app = Flask(__name__)

@app.post("/chaospay/callback")
def chaospay_callback():
    p = request.get_json()
    message = "|".join(str(v) for v in [p["transaction_id"], p.get("order_id") or "", p["amount"], p["status"], p["idrpayment_id"]])
    expected = hmac.new(b"YOUR_SECRET_KEY", message.encode(), hashlib.sha256).hexdigest()

    if not hmac.compare_digest(expected, str(p.get("signature_v2", ""))):
        return "invalid signature", 401

    if int(p["status"]) == 1:
        pass  # mark the order as paid (once — notifications can repeat)
    return "OK", 200

Payout Callback

When a payout becomes success or failed, we send a POST with a JSON body to your withdrawal callback URL. This covers payouts requested by API and from the dashboard (payout_id is then null).

Payload

{
  "payout_id": "PO-2026-0001",
  "withdraw_id": 41,
  "reference": "October settlement",
  "amount": 1500000,
  "fee": 5000,
  "status": "success",
  "note": "October settlement",
  "processed_at": "2026-10-21T14:35:12+07:00",
  "signature_v2": "9b0e44c1d2f3...7a10"
}

Field	Type	Description
`payout_id`	string \| null	Your reference
`withdraw_id`	integer	Our reference
`reference`	string	The note, or the `payout_id` when no note was given
`amount`	integer	Amount in IDR the bank receives
`fee`	integer	Withdraw fee charged on top (refunded when `failed`). Not part of `signature_v2`.
`status`	string	`success` or `failed`
`note`	string \| null	Processing note
`processed_at`	string \| null	ISO 8601
`signature_v2`	string	HMAC-SHA256

Formula

signature_v2 = hmac_sha256_hex(withdraw_id|payout_id|amount|status, secret_key)

<?php
$secretKey = 'YOUR_SECRET_KEY';
$p = json_decode(file_get_contents('php://input'), true);

$expected = hash_hmac('sha256', implode('|', [
    $p['withdraw_id'], $p['payout_id'] ?? '', $p['amount'], $p['status'],
]), $secretKey);

if (! hash_equals($expected, (string) ($p['signature_v2'] ?? ''))) {
    http_response_code(401);
    exit('invalid signature');
}

// $p['status'] is "success" or "failed". Apply it once per withdraw_id.

http_response_code(200);
echo 'OK';

// Express example
const crypto = require('crypto');

app.post('/chaospay/payout-callback', express.json(), (req, res) => {
  const p = req.body;
  const expected = crypto.createHmac('sha256', 'YOUR_SECRET_KEY')
    .update([p.withdraw_id, p.payout_id ?? '', p.amount, p.status].join('|'))
    .digest('hex');

  const given = Buffer.from(String(p.signature_v2 || ''));
  if (given.length !== expected.length || !crypto.timingSafeEqual(given, Buffer.from(expected))) {
    return res.status(401).send('invalid signature');
  }

  // p.status is "success" or "failed". Apply it once per withdraw_id.
  res.status(200).send('OK');
});

# Flask example
import hashlib, hmac
from flask import Flask, request

app = Flask(__name__)

@app.post("/chaospay/payout-callback")
def chaospay_payout_callback():
    p = request.get_json()
    message = "|".join(str(v) for v in [p["withdraw_id"], p.get("payout_id") or "", p["amount"], p["status"]])
    expected = hmac.new(b"YOUR_SECRET_KEY", message.encode(), hashlib.sha256).hexdigest()

    if not hmac.compare_digest(expected, str(p.get("signature_v2", ""))):
        return "invalid signature", 401

    # p["status"] is "success" or "failed". Apply it once per withdraw_id.
    return "OK", 200

Delivery & Retries

Answer with any HTTP 2xx status to acknowledge. Anything else, or no answer within 5 seconds (default), counts as a failure.
A failed delivery is retried, by default for 3 attempts in total, waiting about 10, 60 and 300 seconds between attempts (300 seconds for any further attempt your account is set to).
Callback URLs must use https and resolve to a public address. Redirects are not followed.
The same notification can arrive more than once. Make your handler idempotent: key it on transaction_id (or withdraw_id) and apply each final state once.
Every delivery and its response is listed in the dashboard under Callback Log, where a failed one can be sent again.
Always verify signature_v2 before trusting a callback, and check the amount against your order.
A payment that simply runs past expire_date may not produce a callback. For an order still open after its expiry, ask Payment Status.

Legacy Endpoints

Older integrations can keep using these aliases. They behave exactly like the current endpoints. New integrations should use the current paths.

Legacy	Current
`POST /services/CreatePayment.php`	`POST /payment`
`GET /services/GetStatus.php`	`GET /payment/status`

The API key is accepted only in the X-API-KEY header, never in the URL.

Health Check

GET/up

Returns HTTP 200 when the API is up. No authentication.

Support

For credentials, enabling payouts by API, or questions about a specific transaction, contact your account manager and include the transaction_id or withdraw_id. Never send your secret key to anyone, including us.
